ALUMINUM SPLICE 800MCM (1.031" WIRE DIAMETER) GRAY
Main image
Click to view image in fullscreen
![]()
SKU:
BCUA080
Material:
Aluminum
$53.60
/EA
Download Spec Sheet
Manufactured In: United States
Shipping: Available to ship in: 1-2 Days
Ships from our warehouse in Sanborn, NY 14132
Need Help
Talk to a Product Expert M-F 8am-5:30pm EST
Email us for Quick Support
Aluminum Crimp Splices Product Details:
BCUA series aluminum splices are rated for voltages up to 35KV provided the connector is taped in accordance with accepted practices. Maximum voltage is 5KV in bare splice applications. Each aluminum splice is pre-filled with oxide inhibitor and capped.
Style - Seamless, One Piece Splice
Material - Pure Aluminum with Tin Plating
Wire Range - 800MCM Stranded
Color Code - Gray
Wire Diameter - 1.031"
Length - 4-3/4"
O.D - 1-21/32"
Approvals
UL - AL9CU
CSA
| Spec Sheets | 83WMP.pdf |
|---|---|
| Type | Splice |
| Made In | United States |
| Shipping | 1-2 Days |
| Unit of Measure Quantity | 1 |
| Unit Of Measure | EA |
